easYgen™ 3000
easYgen™ 3000
Description
The easYgen-3000 is an exceptionally versatile genset control and protection package with all the flexibility and features needed to fit a wide range of power generation applications. It allows the user to standardize on a single, affordable control for many uses – from stand-alone emergency generators to isochronous parallel operation of up to 32 gensets. Common applications include emergency stand-by, cogeneration, marine ship/shore power, island prime power or utility paralleling with peak shaving and import/export control.
Flexibility
The easYgen-3000 is available in two mounting styles: the back-panel-mounted easYgen-3100/3400 has a rugged aluminum chassis for use in harsh environments or confined spaces, the flush-mounted easYgen-3200/3500 has sealed soft keys and a large, easy to read back-lit display. The lS-5 circuit breaker control, when used with the easYgen-3400/3500, enables complex control of distribution systems having multiple mains and bus tie breakers. The integrated logicsManager TM links internal states and input signals with logical operators and time elements to implement complex control tasks.
easYgen™ 3000
For a wide range of applications – from simple standby generators to utility parallel of up to 32 gensets – all in one unit
Features
- load share 32 gensets in island mode or paralleled to a single utility
- load-dependent start/stop
- Control 0, 1, 2 or 3 breakers, open or closed transition, with synchronization and soft load/unload
- Can be combined with Rp-3000 remote panel and lS-5 system
- Complete engine/generator protection + mains monitoring
- Advanced communication (CANopen, J1939 and Modbus) to engine ECUs, plCs, HMI, SCAdA and external I/O
- display panel can be configured in different languages
